Laser   output power

6000w

Laser   repetition frequency

 6000W

Energy   instability

≤2%

Minimum   line width

0.2mm   ( ≤0.4mm thickness material)

Maximum   working speed

≤10m/min   (Speed maybe different as for different material)

Continuous   working time

≥   22 hours

Maximum   Working area

1500*3000mm

Worktable   mechanical precision

±0.1mm

Resetting   Positioning Accuracy

±0.1mm

Power   Supply

220V±5% /50HZ ±1%

Software

The   software has segment cut function

Net   weight

3000Kg

Grow weight

3500KG

Machine size

 4600*2200*800mm

Packing size

 4800*2300*1600mm

Materials

Thickness (mm)

Speed (m/min)

Air

Stainless   steel

1

30-60

N2

2

30-36

N2

3

15-20

N2

4

11-14

N2

5

 7-8

N2

6

5-6

N2

8

 3.8-4.2

N2

10

1.8-2.2

N2

11.5

1.2-1.5

N2

14

0.9-1

N2

16

0.65-0.75

N2

Carbon steel

Carbon   steel

1

 40-45

N2

3

4-4.5

O2

5

 3.2-3.7

O2

6

 2.8-3.4

O2

8

 2.5-2.8

O2

10

 1.4-2.2

O2

12

 0.9-1.8

O2

16

 0.7-1

O2

18

0.65-0.75

O2

20

0.6-0.7

O2

22

0.55-0.65

O2

Aluminum

1

 30-50

N2

2

 20-30

N2

3

 12-16

N2

4

 10-12

N2

5

 6-10

N2

8

1.2-2

N2

10

0.8-1

N2

12

0.5-0.7

N2

14

0.4-0.6

N2

Brass

1

35-50

N2

2

20-30

N2

3

10-16

N2

4

6-8

N2

5

4.5-6.5

N2

6

3-4

N2

8

1.2-1.8

N2

Red   copper

1

 25-35

O2

2

 7-10

O2

3

2-3

O2

4

1-2

O2

6

0.6-0.8

O2
